GIRA
2004 600
Room climate sensor Standard for KNX System 55, stainless steel (lacquered)
Product code:
2004 600
Room climate sensor with integrates bus coupler.
Description
- Room temperature auxiliary unit for a heating actuator with controller.
- Segment-based display: Display of the operating mode (comfort, lowering temperature, night-time lowering, eco), window status, operation lock, boost function, heating/cooling mode
- Display brightness can be configured incl. day/night mode.
- Integrated temperature sensor.
Operating functions
- Setpoint adjustment.
- Operating mode change.
- Operation lock can be set manually, automatically after a set time or via an object.
- Switch on/off function.
- Boost function.
- Heartbeat function: Check whether the application is running without errors.
Controller auxiliary unit
- Control of heating actuators for KNX with integrated controller.
- Change the operating mode of the room temperature controller.
- Adjust the target temperature of the room temperature controller.
Technical Details
Specification
KNX medium: TP256
KNX current consumption: 8 to 14 mA
KNX connection: Connection and junction terminal
Protection class: III
Installation depth: 19 mm
Ambient temperature: -5 °C to +45 °C
Relative humidity: 5 to 95% (no condensation)
Properties
Properties
| Technology | KNX |
| Brand | GIRA |
| Design range | GIRA System 55 |
| Switch action | Push Button |
| Mounting | Depends on Frame Choice |
| Display | Monochrome LCD |
| Back Box | Round European |
| Operating voltage | KNX Bus (29VDC) |
| HVAC support | Temperature Sensing + Regulation |
| Status LED's | Red Blue or Green |
| Buscoupler | Not Included |
