THEBEN
S360 KNX UP WH
theRonda KNX Passive infrared presence detector, white
Product code:
2089520
KNX Passive infrared presence detector for ceiling installation
Circular detection area 360°, up to Ø 8 m (50 m²) at 3 m installation height
Automatic presence and brightness dependent control for lighting and HVAC
Description
- Mixed light measurement suitable for fluorescent (FL/PL/ESL), halogen/incandescent lamps and LEDs
- 2 light channels C1, C2
- Switching operation or constant light control with standby function (orientation light)
- Switching mode with dimmable lighting
- Choice of fully or semi-automatic
- Brightness switching value or set point value can be set in lux by using parameters, the object or via remote control
- Teach-in of the brightness switching value or the set point value
Technical Details
Specification
Installation height: 2 – 4 m
Minimum height: > 1,7 m
Measuring range brightness: 10 – 3000 lx
Detection angle: 360°
Type of connection: KNX bus terminal
Installation type: Ceiling installation
Light switch-off delay: 30 s – 60 min
Light measurement: Mixed light measurement
Presence switch-off delay: 10 s - 120 min
Switch-on delay presence: 10 s – 30 min / inactive
Ambient temperature: -15°C ... 50°C
Detection range: 50 m² (ø 8 m | 360°)
Colour: White
Type of protection: IP 54 (when fitted)
Properties
Properties
| Technology | KNX |
| Brand | THEBEN |
| Colour/Material | White |
| Mounting | Flush |
| Back Box | Round European |
| Operating voltage | KNX Bus (29VDC) |
| Buscoupler | Integrated |
| IP rating | IP54 |
