THEBEN
360 DALI-2 S DE WH
PlanoSpot Passive infra-red DALI-2 presence sensor
Product code:
2030190
Passive infra-red presence sensor for ceiling installation in false ceilings, DALI-2 certified
Description
- Square detection area 360°, 7 x 7 m, (49 m2) at mounting height 3 m
- This device provides information about presence and brightness in the form of a DALI telegram in line with IEC 62386 Part 303/304
- 2 instances for presence - detection zone standard/reduced
- Optics can be tilted to adjust the detection area
- 3 mixed light measurements
- 4 instances for brightness - interior/centre/window/integral
- Easy to calibrate brightness measurement
- Test mode for checking function and detection area
- Configurable detection sensitivity
Technical Details
Specification
Operating voltage: DALI
Installation height: 2 – 3 m
Maximum height: 3.5 m
Minimum height: > 1.7 m
Measuring range brightness: 10 – 10000 lx
Detection angle: 360°
Installation type: Ceiling installation
Light measurement: Mixed light measurement
Ambient temperature: 0°C ... 50°C
Detection range: 49 m² (7,0 x 7,0 m)
Colour: White
Type of protection: IP 20
Properties
Properties
| Technology | DALI |
| Brand | THEBEN |
