THEBEN
OKTO 540 BN
Electronical latching relay
Product code:
5400030
Description
- Electronical latching relay
- Comfortable lighting control of one common consumer with several push-buttons possible
- Particularly quiet operation of the installation switch
- Lamps-friendly due to zero-crossing switching
- Ultra-compact design for flexible installation options
- Standby consumption only 0.2 W
- Pre-assembled cables for quick and secure installation
- Dimensions 32.7 x 26.6 x 9.6 m
Technical Details
Specification
Operating voltage: 230 V AC
Frequency: 50 - 60 Hz
Installation type: Flush-mounted
Stand-by consumption: ~0.2 W
Incandescent/halogen lamp load: 250 W
LED lamp 2-8 W: 150 W
LED lamp > 8 W: 150 W
Zero-cross switching: Yes
Housing and insulation material: High-temperature resistant, self-extinguishing thermoplastic
Ambient temperature: -10°C ... 45°C
Protection class: II
Properties
Properties
| Technology | Standard Electrics |
| Brand | THEBEN |
