THEBEN
RME 8 T KNX
KNX 8-way switching or 4-way blind actuator Extension Module MIX2
Product code:
4930205
The MIX2 series is a range of devices consisting of basic modules and extension modules. Up to 2 MIX or MIX2 extension modules can be connected to a basic module of this series. A wide range of functions can be controlled including Dimming, Switching, Heating, Binary Inputs and Blind Actuators.
Description
- 8-way switching or 4-way blind actuator MIX2
- Extension module MIX2
- For upgrading to maximum of 24 channels
- Flexible channel function selection as switching actuator or for controlling drives for blinds, shutters, sun and vision protection devices, skylights and ventilation flaps
- Up to two extension modules MIX or MIX2 can be connected to one base module
- Device and KNX bus module can be swapped independently of each other, Removable KNX bus module enables devices to be changed without reprogramming
- Manual set-up and use of actuator is possible without KNX bus module
- LED switching status display for each channel
- Manual operation on device (even without bus connection)
Technical Details
Specification
Operating Voltage: Via Base Module
Outputs: 8
Output Rated Voltage: 240VAC
Type of Contact: NO contact, Potential Free
Current Rating: 16A (cos =1), 3A (cos=0.6)
Properties
Properties
| Technology | KNX |
| Brand | THEBEN |
| Mounting | DIN Rail |
| Operating voltage | KNX Bus (29VDC) |
| Outputs | 8 |
| IP rating | IP20 |
| Mounting Width | 4MW |
